AMD Radeon Pro WX 4100 GPU - System Overview
Description
The newly AMD-developed Polaris chips are an integral part of the AMD WX 4100 GPU. With upgrades in their drivers, AMD has reestablished its standing with the workstation GPU industry.
Memory
To ensure solid GPU performance, AMD has outfitted the AMD Radeon WX 4100 with 4GB of GDDR5 memory. The unit is built with a 128-bit Memory Bus and up to 96 GB/s of bandwidth.
Performance
This unit has a base clock speed of 1125 MHz which can be boosted to 1201 MHz. Performance ratings come at 2.460 TFLOPS for FP16 and FP32 performance points. The FP 64 performance point comes in at 153.7 GFLOPs.
Cooling
Much like the other products in the WX family, the Radeon WX 4100 comes with a unique cooling architecture. Closed channel aluminum fins can be found above vaper channels within the unit. The built-in fans are made by Delta and are found in many of AMD's products. With fans speeds of up to 5000 RPM, they are not the quietest but are very effective.
Summary
As a new entry in AMD's product line, the AMD Radeon Pro WX 4100 is a workstation-level GPU for graphic design and video production professionals. The 4GB of GDDR5 memory and Polaris-chip architecture provide very solid performance for its value.
