Dell EMC PowerEdge XR11 Server

Built for conditions at the edge, the 1U, 4-bay Dell EMC PowerEdge XR11 server is built to withstand extreme environments and industrial applications. The ruggedized system is MIL-STD, NEBS, and Marine compliant at only 16 inches deep. It features 4x 2.5-inch SATA/SAS/NVMe SSD front storage bays and can accommodate a single 3rd generation Intel Xeon Scalable processor with up to 36 cores. This system can be outfitted with 8x DDR4 memory modules for up to 512GB when using RDIMMs or up to 1TB of RAM when using LRDIMMs. Mmeory speeds of up to 3200MT/s can be achieved. Up to 4x Intel Optane PMem 200 series modules can also be utilized for a maximum of 512GB.
Dell EMC PowerEdge XR11 side view
Dell Technologies Authorized Partner Intel Partner Gold AMD Executive Elite System Builder NVIDIA Elite Partner

Dell EMC PowerEdge XR11 Server - System Overview

Ideal for telecommunications, military, retail, and restaurants, the PowerEdge XR11 server offers 2x 70W single-width GPUs. Conditions like extreme temperatures, shock, vibration, and dust are no match for this system. The air-cooled chassis has 6x cold-swap fans that keep all of the components at operational temaperatures. It has 4x 25GbE SFP+ LOM and 3x PCIe Gen4 slots. A number of power supply options include 1400W Platinum, 1100W DC, or 800W Platinum PSUs.

Dell EMC PowerEdge XR11 server front drive bays Dell EMC PowerEdge XR11 server rear ports

Dell EMC PowerEdge XR11 Server - Specifications

Processor - 1 Socket

  • 1x 3rd Generation Intel Xeon Scalable processor
  • Up to 36 cores per CPU

Memory

  • 8x DDR4 DIMM slots
  • Supports RDIMM 512GB max
  • Supports LRDIMM 1TB max
  • Speed: Up to 3200MT/s

  • Up to 4x Intel Optane PMem 200 Series slots, 512 GB max

Storage

  • 4 x 2.5-inch SATA/SAS/NVMe (SSDs) max 61.44 TB

GPU Options

  • 2 x 70 W SW

Expansion Slots

  • 3 x PCIe Gen4 slots

Controllers

  • Internal Controllers: PERC H755, S150
  • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 SSDs or USB
  • External PERC (RAID): PERC H840
  • 12 Gbps SAS HBAs (non-RAID): internal- HBA355i, external-HBA355e

Ports

    Front Ports

  • 1 x iDRAC Direct (Micro-AB USB) port
  • 1 x USB 2.0

    • Internal Ports

  • 1 x USB 3.0

    • Rear Ports

  • 1 x USB 2.0
  • 1 x USB 3.0
  • 1 x Serial (optional)
  • 1 x dedicated iDRAC Ethernet Port
  • 1 x VGA

OS Compatibility

  • Canonical Ubuntu Server LTS
  • Citrix Hypervisor
  • Microsoft Windows Server with Hyper-V
  • Red Hat Enterprise Linux
  • VMware ESXi
  • SUSE Linux Enterprise Server
  • RHEL Realtime

Power Supply

  • 1400 W Platinum AC/240 HVDC
  • 1100 W LVDC -48 — (-60) VDC
  • 800 W Platinum AC/240 HVDC

Cooling Options

  • Very high performance up to 6x cold swap fans
  • Air cooling

Management

  • iDRAC9
  • iDRAC Service Module
  • iDRAC Direct

OpenManage

  • OpenManage Enterprise
  • OpenManage Power Manager Plugin
  • OpenManage SupportAssist Plugin
  • OpenManage Update Manager Plugin

Security

  • Cryptographically signed firmware
  • Secure Boot Secure Erase
  • Silicon Root of Trust
  • System Lockdown(requires iDRAC9 Enterprise or Datacenter)
  • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Chassis

  • Height – 42.8 mm (1.68 inches)
  • Width – 482.6 mm (19 inches)
  • Depth – 477 mm (18.77 inches) with bezel
  • Depth – 463 mm (18.22 inches) without bezel
  • Depth – 400 mm (15.74 inches) ear to rear wall

Dell EMC PowerEdge XR11 Server - Documentation

Dell EMC PowerEdge XR11 Specifications Sheet Dell EMC PowerEdge XR11 Technical Guide Dell EMC PowerEdge Rack Servers Quick Reference Guide Dell EMC PowerEdge XR11 Installation and Service Manual
