Additional InformationBuilt for high-density storage deployments, the Dell PowerEdge R7725xd supports multiple front-access NVMe configurations. Storage options include up to 24x 2.5-inch U.2 Gen5 NVMe drives for up to 2928TB of storage or up to 40x E3.S or E3.L Gen5 NVMe drives for up to 9.8PB. A BOSS-N1 DC-MHS solution provides dedicated internal boot storage, while internal RAID controllers are not listed as a standard option. The system features 24x DDR5 RDIMM slots with support for up to 3TB of memory and speeds of up to 6400 MT/s. Expansion capabilities include up to 5x full-height PCIe x16 slots, along with an optional OCP NIC 3.0 for additional network connectivity.
Power is supplied by redundant, hot-swappable Titanium-rated power supplies available in 1500W, 1800W, 2400W, and 3200W configurations. Air cooling is handled by up to 6x hot-plug fans, and an optional metal bezel is available for the front of the system. Integrated iDRAC10 provides remote system monitoring and management, with support for iDRAC Direct, iDRAC RESTful API with Redfish, and RACADM CLI. Dell's OpenManage portfolio provides additional tools for managing, monitoring, and maintaining the server throughout its lifecycle.
- 2x 5th Generation AMD EPYC 9005 Series processors
- Up to 192 cores per CPU
- 24x DDR5 DIMM slots
- Supports RDIMM 3TB max
- Speeds up to 6400 MT/s
- Supports registered ECC DDR5 DIMMs only
- Internal Controllers (RAID): N/A
- Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS)
- External HBAs (non-RAID): N/A
Front Bays:
- 24x 2.5-inch U.2 Gen5 NVMe max 2928TB
- 40x E3.S/L Gen5 NVMe max 9.8PB
Up to 5x PCIe slots (x16 connector)
- Slot 2: 1 x16 Gen5 Full Height
- Slot 3: 1 x16 Gen5 Full Height or 1 x16 Gen5 Low Profile
- Slot 4: 1 x16 Gen5 Full Height
- Slot 7: 1 x16 Gen5 Full Height
- Slot 8: 1 x16 Gen5 Full Height
- Slot 9: 1 x16 Gen5 Low Profile
- 1x OCP NIC 3.0 card (optional) and 10GbE
- Slot 10: 1 x4 Gen3 OCP3.0
- 100 GbE and 400GbE; NDR VPI (400GbE)
Front Ports:
- 1x USB 2.0 Type-A (optional LCP-Secondary KVM)
- 1x USB 2.0 Type-C (HOST/BMC Direct)
- 1x Mini DisplayPort (optional LCP-Secondary KVM)
Rear Ports:
- 1x dedicated BMC Ethernet port
- 2x USB 3.1 Type-A
- 1x VGA
Internal Ports:
- 1x USB 3.1 Type-A
- 1500W Titanium 100—240 VAC or 240 HVDC, hot swap redundant
- 1800W Titanium 200-240 VAC or 240 HVDC, hot swap redundant
- 2400W Titanium 100—240 VAC or 240 HVDC, hot swap redundant
- 3200W Titanium 200-240 VAC or 240 HVDC, hot swap redundant
- Air Cooling
- Up to 6x hot-plug fans
- iDRAC 10
- iDRAC Direct
- iDRAC RESTful API with Redfish
- Racadm CLI
- 2U rack server
Height:
- 86.8 mm (3.42 inches)
Width:
- 482 mm (18.98 inches)
Depth (U.2 drives):
- 802.4 mm (31.59 inches) with bezel
- 801.51 mm (31.55 inches) without bezel
Depth (E3.S/L drives):
- 831.85 mm (32.75 inches) with bezel
- 830.96 mm (32.71 inches) without bezel
- Optional metal bezel
- OpenManage Enterprise (OME)
- OME Power Manager
- OME Services
- OME Update Manager
- OME APEX AIOps Observability
- OME Integration for VMware vCenter (with VMware Aria Operations)
- OME integration for Microsoft System Center
- OpenManage Integration for Windows Admin Center
OpenManage Integrations:
- RedHat Ansible Collections
- Terraform Providers
- 1Gb dedicated BMC Ethernet port
