Additional InformationWith 12x memory channels CPUs, and 12x DIMM slots each for 24x total, each memory module delivers optimal performance. Supported processors on the Gigabyte B684-A80 high-density server are limited to 500W. Using Intel Xeon 6 Plus processors the system can deliver up to 288 E-cores per processor for support of hyperscale and cloud-native workloads. Standard Intel Xeon 6900-series processors offer up to 128 P-cores and deliver better core performance for TCO, accelerating AI, and compute-intensive workloads. Only standard 6900-series processor support Multiplexed Rank DIMM (MRDIMM) modules which provide memory speeds at up to 8000MT/s
There are two different versions of this system with one air cooled and the other offering direct liquid cooling.
Gigabyte B684-A80-AAS1
Air cooled, 7+3 3200W PSUs, 10x 80mm x 80mm fans
Gigabyte B684-A80-LAS1
Integrated-manifold full-system DLC, 6+6 3200W PSUs, 4x 80mm x 80mm fans
Each server node has 2x E3.S Gen5 NVMe storage bays per node. 3x low-profile PCIe gen5 x16 slots provide options for NICs. Powering this system are 10x 3200W 80 Plus Titanium power supplies. To manage the system there are 2x Chassis Management Controller LAN ports. Multiple Gigabyte B684-A80 chassis can be connected in a ring topology with a network switch to significantly enhance cluster stability by automatically rerouting traffic if there is a failure. A star topology can be configured using the management LAN (MLAN) ports on the front of the system.
Explore available configurations for the Gigabyte B684-A80 Blade Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
Intel Xeon 6+ Processors
- Intel Xeon 6900E+ Processors
Intel Xeon 6 Processors
- Intel Xeon 6900-Series Processors
- Dual processors per node, TDP up to 500W
- Socket BR
- 20x LGA 7529
- Motherboard: MA84-HD3
- System on Chip
Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable.
- 24x DIMM slots per node
- Support DDR5 RDIMM/MRDIMM
- 12-Channel memory per processor
Intel Xeon 6900E+:
- RDIMM: Up to 8000 MT/s
Intel Xeon 6900-series:
- RDIMM: Up to 6400 MT/s
- MRDIMM: Up to 8800 MT/s
*MRDIMMs are supported only on select Intel Xeon 6 processors with P-cores.
Front hot-swap:
- 2x E3.S Gen5 NVMe per node, from CPU_0
Front:
- 1x 10/100/1000 Mb/s Management LAN per node
Rear (MLAN board):
- 2x Chassis Management LAN
*Spanning Tree Protocol (STP) must be enabled on LAN switches when using a ring topology.
Riser Card x3:
- 2x LP x16 (Gen5 x16) per node, from CPU_0
- 1x LP x16 (Gen5 x16) per node, from CPU_1
Note: Supports ambient temperatures up to 25°C with all three PCIe slots occupied.
Per Node:
- 2x USB 3.2 Gen1 ports (Type-A)
- 1x Mini-DP
- 1x MLAN port
- 1x Power button with LED
- 1x System status LED
- 1 x ID LED
MLAN board:
- 2x CMC ports
- 1x CMC status LED
Rev. AAS1:
- 7+3 3200W 80 PLUS Titanium redundant power supplies
Rev. LAS1:
- 6+6 3200W 80 PLUS Titanium redundant power supplies
*The system power supply requires C19 power cord.
Rev. AAS1:
- 10x 80x80x80mm
Rev. LAS1:
- 4x 80x80x80mm
- 6U 10-Node - Front access
- 447 x 262.3 x 900
- Net Weight: 120 kg
- Gross Weight: 130 kg
