Network communications on the Gigabyte G3L5-DR4-L08 GPU Server include 8x 800Gb/s OSFP InfiniBand ports or Ethernet GPU networking ports via 8x single port NVIDIA ConnectX-9 virtual protocol interconnect (VPI) ports. NVIDIA’s NVLink and NVLink Switch delivers 3.6TB GPU-to-GPU connection speeds. 12x 2.5-inch Gen5 NVMe hot-swap bays line the front of the chassis. To boot the system, 2x PCIe Gen4 x4 slots can be outfitted with 2x NVMe M.2 drives. The system is housed in a rack with a 54V DC Bus Bar and connects automatically.
Each CPU supports 16x DDR5 memory module slots for 32 total between both processors. Supported memory include Registered DIMMs (RDIMM) and Multiplexed Rank DIMMs (MRDIM). MRDIMMs will provide top memory speeds of up to 12800MT/s or using RDIMMs, memory speeds of up to 8000MT/s. A liquid cooled full-height, full-length PCIe Gen6 x16 slot for an NVIDIA BlueField-4 DPU (Data Processing Unit). There is also a 1 Gb/s LAN port on the back of the chassis for remote management of the system.
Explore available configurations for the Gigabyte G3L5-DR4 GPU Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- Dual AMD EPYC 9006 SP7 Server processors
- Liquid-cooled NVIDIA HGX Rubin NVL8
- CPU+GPU direct liquid cooling solution with leak detection
- 8x 800 Gb/s OSFP InfiniBand or Ethernet GPU networking ports via 8 x single-port NVIDIA ConnectX-9 VPI
- 3.6 TB/s GPU-to-GPU bandwidth with NVIDIA NVLink and NVIDIA NVLink Switch
- 16-Channel liquid-cooled DDR5 RDIMM/MRDIMM per CPU with 32 x DIMMs
- 1x 1 Gb/s LAN ports via Intel I210-AT
- 12x 2.5" Gen5 NVMe hot-swap bays
- 2x M.2 slots with PCIe Gen4 x4
- 1x liquid-cooled FHFL PCIe x16 slot with Gen6 x16 lanes for NVIDIA BlueField-4 DPU
- 54 V DC Bus Bar power solution
