CPUs supported on the Gigabyte G495-DB0 GPU Server can provide 96 to 256 physical cores and up to 512 virtual threads, each. With 16-channel memory architecture and 16 memory module slots per processor, memory can run top speed with 1x DIMM per Channel. Memory types supported include Registered DIMMs (RDIMM) and Multiplexed Rank DIMMs (MRDIMM). Using RDIMMs, memory can run at up to 8000MT/s. With MRDIMMs, memory speeds of up to 12800MT/s are supported.
Chassis Configurations
Gigabyte G495-DB0-AM1 GPU Server
- Air-Cooled
In order to support those 8x double-wide GPUs, there are 8x PCIe Gen6 full-height, full-length x16 slots. 2x Gen4 x2 slots on the system board can support up to 2x NVMe M.2 drives that can be used to boot the system. For basic network communications, the system has 2x integrated 10Gb/s LAN ports. For additional expansion, the system includes a 1x full-height, half-length PCIe Gen6 x16 slot located on the front of the chassis that can be outfitted with a high-speed NIC with DPU. The system is powered by 4x 3200W 80 PLUS Titanium redundant power supply units (PSU).
Explore available configurations for the Gigabyte G495-DB0 GPU Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- Dual AMD EPYC 9006 SP7 Server processors
- 32x DIMMs
- 16-Channel DDR5 RDIMM/MRDIMM per CPU
- 2x 10 Gb/s LAN ports via Intel X710-AT2
- 4x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays
- 2x M.2 slots with PCIe Gen4 x2
- 8x FHFL PCIe x16 slots with Gen6 x16 lanes for GPUs
- 1x FHHL PCIe x16 slot with Gen6 x16 lanes on the front side
- 4x 3200 W 80 PLUS Titanium redundant power supplies
Choose components, get instant pricing, and build the perfect server in minutes.
Fast, simple, and completely transparent!
