For storage, the system offers 12x 2.5-inch hot-swap bays for Gen5 NVMe, SATA and SAS-4 storage devices. For OS support without using any of the front drive options, Gigabyte provides 2x PCIe Gen4 slots for NVMe M.2 drives. Supported memory types compatible with the Gigabyte G495-DB1 GPU Server include Registered DIMMs and Multiplexed Rank DIMMs (MRDIMM). MRDIMMs can provide memory speeds of up to 12800MT/s, while RDIMMs can deliver up to 8000MT/s. There are two integrated 10Gb/s LAN ports for basic network communications along with a management LAN port.
Chassis Configurations
Gigabyte G495-DB1-AM1
- Air-Cooling
Along with the 10x full-height, full-length (FHFL) PCIe Gen6 x16 PCIe lanes for up to 10 double-wide GPUs, there are also 2x full-height, half-length (FHHL) PCIe Gen 6x slots with a x16 link width for additional expansion options. Those options include storage controllers and high-speed NICs. The GPUs are connected to the CPUs via PCIe switches. Powering the system are 4x 3200W redundant power supply units (PSU).
Explore available configurations for the Gigabyte G495-DB1 GPU Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- Dual AMD EPYC 9006 SP7 Server processors
- 16-Channel DDR5 RDIMM/MRDIMM per CPU with 32x DIMMs
- Supports up to 10x dual-slot Gen6 GPUs
- 2x 10Gb/s LAN ports via Intel X710-AT2
- 12x 2.5" Gen5 NVMe/SATA/SAS4 hot-swap bays
- 2x M.2 slots with PCIe Gen4 x2
- 10x FHFL PCIe x16 slots with Gen6 x16 lanes for GPUs
- 2x FHHL PCIe x16 slots with Gen6 x16 lanes on the front side
- 4x 3200W 80 PLUS Titanium redundant power supplies
