With 1DPC the platform can support top memory speeds of up to 8000MT/s using Registered DIMMs (RDIMM) or up to 12800MT/s using Multiplexed Rank DIMMs (MRDIMM). 12x 2.5-inch Gen5 NVMe, SATA, SAS-4 drive bays line the front of the Gigabyte G495-DB2 GPU Server. There are also 2x PCIe Gen4 x2 slots for two NVMe M.2 drives that can be used to support the operating system, which includes Linux and Windows options. The system is equipped with 4x 3200W 80 PLUS Titanium redundant power supply units. For basic networking, there are 2x 10Gb/s LAN ports and a dedicated management LAN port.
Gigabyte G495-DB2-AM1 GPU Server
- Air-Cooled
If those integrated networking ports are not enough, there are also 2x full-height, half-length (FHHL) PCIe Gen6 x16 slots and 4x low-profile PCIe Gen6 x16 slots. Those slots can be used for additional NICs, smart NICs and storage controllers. A storage controller is required for SAS drive configurations. 8x Full-height, full-length PCIe Gen6 x16 slots provide support for Gen6 PCIe GPUs. PCIe Gen6 is twice as fast as the previous generation offering a bandwidth of 8GB/s per lane compared to 4GB/s per lane with Gen5 PCIe. This translates to 128GB/s total for a x16 slot with a x16 link width in one direction or 256GB/s bidirectional.
Explore available configurations for the Gigabyte G495-DB2 GPU Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- 2x AMD EPYC 9006 SP7 Server Processors
- 32x DIMMs
- 16-Channel DDR5 RDIMM/MRDIMM per CPU
- Supports up to 8x dual-slot Gen6 GPUs (with PCIe switches)
- 2x 10 Gb/s LAN ports via Intel X710-AT2
- 12x 2.5" Gen5 NVMe/SATA/SAS4 hot-swap bays
- 2x M.2 slots with PCIe Gen4 x2
- 8x FHFL PCIe x16 slots with Gen6 x16 lanes for GPUs
- 2x FHHL PCIe x16 slots with Gen6 x16 lanes
- 4x LP PCIe x16 slots with Gen6 x16 lanes
- 1x FHHL PCIe x16 slot with Gen6 x16 lanes on the front side
- 4x 3200W 80 PLUS Titanium redundant power supplies
