Featuring 1x AMD EPYC 9005 or 9004 Series processor with up to 192 CPU cores, the R163-ZG2 delivers 12-channel DDR5 memory architecture across 24x DIMM slots for up to 3TB total memory capacity. With an EPYC 9005 installed it supports memory speeds of up to 5200 MT/s with 1DPC or up to 4400 MT/s single rank modules with 2DPC or speeds of up to 4000 MT/s using dual rank modules at 2DPC. Outfitted with AMD EPYC 9004 series processors memory speeds of up to 4800 MT/s (1DPC) or 3600 MT/s (2DPC). PCIe expansion includes 3x PCIe Cable slots (1 x FHFL x16 Gen5 for GPUs, 1 x FHFL x16 Gen5, and 1 x FHHL x16 Gen5) plus 1 x OCP NIC 3.0 (Gen5 x16) with NCSI support.
The server supports 1x dual-slot Gen5 GPU along with additional PCIe Gen5 expansion slots for networking and hard drive controller cards. Storage includes 12x 2.5-inch Gen5 NVMe/SATA/SAS4 hot-swap bays at the front and 2x internal M.2 slots. Networking options include an OCP NIC 3.0 slot for high-speed connectivity. The server comes with 1+1 redundant 2000W 80 PLUS Titanium power supplies, closed-loop cooling support, and ASPEED AST2600 BMC for remote management. This configuration optimizes the system for AI inference, visual computing, private cloud deployments, and high-density rack environments.
Explore available configurations for the Gigabyte R163-ZG2 Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
*SAS card is required to support SAS drives.
*Blocked when a dual-slot GPU is installed.
Choose components, get instant pricing, and build the perfect server in minutes.
Fast, simple, and completely transparent!
