Additional InformationThe TO15-Z40-IA01 features 2x AMD EPYC 9005 or 9004 Series processors with a cTDP of up to 400W per CPU. It is important to note that if only one CPU is installed, some PCIe or memory functions might be unavailable. This system is equipped with 24x DDR5 RDIMM slots with 12 DIMM slots per processor. Memory speeds reach up to 6400 MT/s with 9005 Series processors and up to 4800 MT/s with 9004 Series processors.
For storage, administrators can take advantage of 4x top-loading hot-swap 15mm E1.S NVMe drive bays, plus an optional internal 2x M.2 SATA slots for 2280 or 22110 cards. In total there are 6x PCIe Gen5 expansion slots. Up to 4x double-wide GPUs are supported using the 4x full-height, full-length slots x16 slots. Alternatively, 8x full-height, full-length PCIe slots can be installed to support up to 8x single-width GPUs. The low-profile slots provide options for networking.
Riser Card CORC206 x 2:
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_0, for GPUs
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_1, for GPUs
Riser Card CORC207 x 2:
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_0, for GPUs
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_1, for GPUs
Riser Card CRSG01F x 2:
- 2 x LP x16 (Gen5 x16), from CPU_0
The ASPEED AST2600 BMC provides full remote management capabilities via the Gigabyte Management Console web interface. Key features include HTML5 KVM for remote desktop access, comprehensive sensor monitoring, power management tools, detailed event logging, and multiple user authentication methods. The server utilizes a 48V DC bus bar design optimized for high-power GPU setups, ideal for dense AI and HPC workloads in OCP ORv3 environments.
Explore available configurations for the Gigabyte TO15-Z40-IA01 GPU Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- AMD EPYC 9005 Series Processors
- AMD EPYC 9004 Series Processors
- Dual processors, cTDP up to 400W
*If only 1 CPU is installed, some PCIe or memory functions might be unavailable
- ORv3
- 24x DIMM slots
- Support DDR5 RDIMM
- 12-Channel memory per processor
AMD EPYC 9005:
- Up to 6400MT/s
AMD EPYC 9004:
- Up to 4800MT/s
Top:
- 2x 10Gb/s LAN (1 x Broadcom BCM57416)
- Support NCSI function
- 1x 10/100/1000 Mbps Management LAN
Top hot-swap:
- 4x 15mm E1.S NVMe
Optional internal M.2 (COMTP61):
- 2x M.2 (2280/22110), SATA, from CPU_1
Riser Card CORC206 x 2:
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_0, for GPUs
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_1, for GPUs
Riser Card CORC207 x 2:
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_0, for GPUs
- 1 x FHFL x16 (Gen5 x16) or 2 x FHFL x16 (Gen5 x8), from CPU_1, for GPUs
Riser Card CRSG01F x 2:
- 2 x LP x16 (Gen5 x16), from CPU_0
- 2x USB 3.2 Gen1 ports (Type-A)
- 1x VGA port
- 2x RJ45 ports
- 1 x MLAN port
- 1x Power button with LED
- 1x ID button with LED
- 1x NMI button
- 1x Reset button
- 1x System status LED
- ASPEED AST2600 Baseboard Management Controller
- Gigabyte Management Console web interface
OS Certifications:
- Windows Server 2022
- Windows Server 2025
- 1x 48V Bus Bar
- 1OU
- 537 x 45 x 805.7
- Net Weight: 24.04 kg
- Gross Weight: 29.04 kg
