Additional InformationWith Package Power Tracking (PPT) for the CPUs rated at up to 600W, processors with up to 256 cores and 512 virtual threads are supported. Designed for scalable computing, the Gigabyte TO17-D81-L01 Server supports DDR5 RDIMMs or Multiplexed Rank DIMM (MRDIMM) modules. Memory speeds of 8000MT/s are supported using RDIMMs or up to 12800MT/s using MRDIMMs. Each node has access to 2x E3.S Gen6 NVMe hot swap drive bays.
For expansion, each node offers 3x low-profile Gen6 x16 slots. This platform is designed for an Open Rack Version 3 (ORV3) open-standard 21-inch server cabinet. The cabinet also has a 48V DC vertical Busbar, which the servers plug into that eliminates the cabling from server power cords. There is a management LAN port on the front of each server node.
Explore available configurations for the Gigabyte TO17-D81-L01 Server. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- AMD EPYC 9006 SP7 processors
- Dual processors per node, PPT up to 600W
- Motherboard: MD85-HD0
If only 1 CPU is installed, some PCIe or memory functions might be unavailable.
- ORV3
- 32x DIMM slots per node
- Support DDR5 RDIMM/MRDIMM*
- 16-Channel memory per processor
- RDIMM: Up to 8000 MT/s
- MRDIMM: Up to 12800 MT/s
*MRDIMMs are supported only on select CPU SKUs.
Front hot-swap:
- 2x E3.S Gen6 NVMe per node, from CPU_0
Front:
- 1x Management LAN per node
Integrated in ASPEED AST2700
- 1x Mini-DP per node
Riser Card x 3:
- 2x LP x16 (Gen6 x16) per node, from CPU_0
- 1x LP x16 (Gen6 x16) per node, from CPU_1
Per node:
- 2x USB 3.2 Gen1 ports (Type-A)
- 1x Mini-DP
- 1x MLAN port
- 1x Power button with LED
- 1x System status LED
- 1x ID LED
- 48V to 54V DC bus bar power solution
- 1OU 2-node front access server system
