Product Details:
NVIDIA TITAN RTX TURING GPU 24GB 4608 CUDA CORES MEMORY INTERFACE 384 BIT GDDR6 MEMORY BANDWIDTH 672GB/S PCI-E 3.0 X16 ( 3 ) THREE DISPLAYPORTS DP ( 1 ) ONE HDMI ( 1 ) ONE USB TYPE C GRAPHICS PROCESSING UNIT VIDEO CARD - BASE CLOCK 1350MHZ BOOST CLOCK 1770MHZ MEMORY CLOCK 7000MHZ MEMORY DATA RATE 14GB/S TENSOR CORES 576 RT CORES 72 ( 1 ) ONE NVLINK INTERFACE ( 2 ) TWO 8 PIN POWER CONNECTORS
MANUFACTURER: NVIDIA
PART NUMBER: TITAN RTX
ENGINE SPECS:
ENGINE ARCHITECTURE: TURING
GRAPHICS PROCESSING CLUSTERS: 6
TEXTURE PROCESSING CLUSTERS: 36
STREAMING MULTIPROCESSORS: 72
CUDA CORES: 4608 ( SINGLE PRECISION )
TENSOR CORES: 576
NVIDIA RT CORES: 72
SINGLE PRECISION FLOATING PERFORMANCE ( FP32 ): 16.3 TFLOPS ( TERA FLOPS )
HAFL PRECISION FLOATING PERFORMANCE ( FP16 ): 32.62 TFLOPS ( TERA FLOPS )
TENSOR PERFORMANCE: 130 TFLOPS ( TERA FLOPS )
GPU CLOCK: 1350 MHZ
BOOST CLOCK: 1770 MHZ
TEXTURE RATE ( BILINEAR ): 510 GIGATEXELS/SEC
FABRICATION PROCESS ( NM ): 12NM FFN
TRANSISTOR COUNT: 18.6 BILLION
MEMORY:
MEMORY CONFIGURATION: 24GB
MEMORY INTERFACE: GDDR6
MEMORY INTERFACE WIDTH: 384 BIT
MEMORY BANDWIDTH: 672 GB/S
MEMORY CLOCK: 7000 MHZ
MEMORY DATA RATE: 14GB/S
SUPPORT:
BUS SUPPORT: PCI-E 3.0
PHYSICAL BUS INTERFACE: PCI-E 3.0 X16
SUPPORTED TECHNOLOGIES: REAL-TIME RAY TRACING, NVIDIA GEFORCE EXPERIENCE, NVIDIA SHADOWPLAY, NVIDIA ANSEL, NVIDIA HIGHLIGHTS, NVIDIA G-SYNC READY, GAME READY DRIVERS, MICROSOFT DIRECTX 12 API, VULKAN API, OPENGL 4.6, OPENCL 1.2, NVIDIA NVLINK SUPPORT, NVIDIA CUDA TECHNOLOGY, DIRECTCOMPUTE, OPENCL, PCI EXPRESS GEN3
OPERATING SYSTEMS: MICROSOFT WINDOWS 7 ( 64 BIT ), MICROSOFT WINDOWS 10 ( 64 BIT / APRIL 2018 UPDATE OR LATER ), LINUX ( 64 BIT )
DISPLAY SUPPORT:
MULTI MONITOR: YES ( UP TO 4 MONITORS )
RESOLUTION:
4X 4096 X 2160 AT 120HZ
4X 5120 X 2880 AT 60HZ
2X 7680 X 4320 AT 60HZ
CONNECTIONS:
DISPLAY CONNECTORS: ( 3 ) THREE DISPLAYPORTS DP ( 1 ) ONE HDMI ( 1 ) ONE USB TYPE C ( VITUALLINK CONNECTOR )
POWER CONNECTORS: ( 2 ) TWO 8 PIN POWER CONNECTORS
ADDITIONAL CONNECTORS: ( 1 ) ONE NVLINK INTERFACE ( 100GB/S BIDIRECTIONAL )
THERMAL AND POWER SPECS:
THERMAL DESIGN POWER ( TDP ): 280W
RECOMMENDED POWER SUPPLY ( W ): 650W
THERMAL THRESHOLD: 89 DEGREES CELSIUS
COOLING SYSTEM:
ACTIVE - DUAL FANSINK ( X2 FANS )
FORM FACTOR:
DUAL SLOT, FULL HEIGHT
