Product Details:
NVIDIA RTX A4500 GPU 20GB 7168 CUDA CORES MEMORY INTERFACE 320 BIT GDDR6 MEMORY BANDWIDTH 640GB/S PCI-E 4.0 X16 ( 4 ) FOUR DISPLAYPORTS DP GRAPHICS PROCESSING UNIT VIDEO CARD - AMPERE ARCHITECTURE
MANUFACTURER: NVIDIA
PART NUMBER: NVIDIA RTX A4500-RETAIL
CONTENT INCLUDES: ( 1 ) ONE NVIDIA RTX A4500 GPU ( 1 ) ONE MALE DP TO FEMALE HDMI CABLE ADAPTER
ENGINE SPECS:
ENGINE ARCHITECTURE: AMPERE
CUDA CORES: 7168
3RD GEN TENSORE CORES: 224
2ND GEN RT CORES: 56
SINGLE PRECISION PERFORMANCE: 23.7 TFLOPS
RT CORE PERFORMANCE: 46.2 TFLOPS
TENSOR PERFORMANCE: 189.2 TFLOPS
GPU CLOCK: 1050 MHZ
BOOST CLOCK: 1650 MHZ
PROCESS SIZE: 8NM
TRANSISTORS: 28.3 BILLION
DIE SIZE: 628 MM SQUARE
MEMORY:
MEMORY CONFIGURATION: 20GB
MEMORY INTERFACE: GDDR6
MEMORY INTERFACE WIDTH: 320 BIT
MEMORY BANDWIDTH: 640 GB/S
MEMORY CLOCK: 16 GB/S
SUPPORT:
BUS SUPPORT: PCI-E 4.0
PHYSICAL BUS INTERFACE: PCI-E 4.0 X16
SUPPORTED TECHNOLOGIES: NVIDIA AMPERE TECHNOLOGY, CUDA CORES TECHNOLOGY, 2ND GEN RT CORES, 3RD GEN TENSOR CORES, HIGHER SPEED GDDR6 MEMORY, DIRECTX 12.07, SHADER MODEL 5.17, OPENGL 4.68, VULKAN 1.2, DIRECTCOMPUTE, OPENCL, AV1 DECODE SUPPORT, DISPLAYPORT WITH AUDIO, 3D STEREO SUPPORT WITH STEREO CONNECTOR, NVIDIA GPUDIRECT FOR VIDEO SUPPORT, NVIDIA QUADRO SYNC II COMPATIBILITY, NVIDIA RTX EXPERIENCE, NVIDIA RTX DESKTOP MANAGER SOFTWARE, NVIDIA RTX IO SUPPORT, HDCP 2.2 SUPPORT, NVIDIA MOSAIC TECHNOLOGY, NVIDIA NVLINK TECHNOLOGY, VR READY, PCI EXPRESS GEN4
ERROR CORRECTION CODE ( ECC ): YES
NVIDIA NVLINK BANDWIDTH: 112.5GB/S ( BIDIRECTIONAL )
OPERATING SYSTEM: MICROSOFT WINDOWS 10 64 BIT / LINUX 64 BIT
DISPLAY SUPPORT:
DISPLAY RESOLUTION: 7680 X 4320 AT 60HZ ( 2 DISPLAYS ) OR 5120 X 2880 AT 60HZ ( 4 DISPLAYS ) OR 4096 X 2160 AT 120HZ ( 4 DISPLAYS )
MULTI MONITOR: YES, UP TO 4 DISPLAYS
CONNECTIONS:
DISPLAY CONNECTORS: ( 4 ) FOUR DISPLAYPORTS DP
POWER CONNECTORS: ( 1 ) ONE 8 PIN CONNECTOR
ADDITIONAL CONNECTORS: ( 1 ) ONE NVLINK INTERFACE ( 1 ) ONE 14 PIN SYNC CONNECTOR ( 1 ) ONE 4 PIN STEREO CONNECTOR
THERMAL AND POWER SPECS:
TOTAL BOARD CONSUMPTION ( W ): 200W
SYSTEM REQUIREMENTS:
RECOMMENDED PSU ( W ): 550W
COOLING SYSTEM:
ACTIVE - ( 1 ) ONE ACTIVE FANSINK ( SINGLE FAN BLOWER )
FORM FACTOR:
DUAL SLOT
DIMENSIONS:
4.4 INCH ( H ) X 10.5 INCH ( L )
