Product Details:
PNY GEFORCE RTX 5080 GPU 16GB 10752 CUDA CORES MEMORY INTERFACE 256 BIT GDDR7 MEMORY BANDWIDTH 960GB/S PCI-E 5.0 X16 ( 3 ) THREE DISPLAYPORTS DP ( 1 ) ONE HDMI GRAPHICS PROCESSING UNIT VIDEO CARD - NVIDIA BLACKWELL ARCHITECTURE TRIPLE FAN - TRIPLE SLOT
MANUFACTURER: PNY
PART NUMBER: VCG508016TFXPB1-RETAIL
CONTENT KIT INCLUDES: ( 1 ) ONE PNY / NVIDIA GEFORCE RTX 5080 GPU ( 1 ) ONE POWER CABLE
ENGINE SPECS:
ENGINE ARCHITECTURE: NVIDIA BLACKWELL
CUDA CORES: 10752
TENSORE CORES: 336
RT CORES: 84
SINGLE PRECISION PERFORMANCE: 27.8 TFLOPS
RT CORE PERFORMANCE: 171 TFLOPS ( 4TH GEN )
TENSOR PERFORMANCE: 1801 AI TOPS ( 5TH GEN )
GPU CLOCK: 2.30 GHZ
BOOST CLOCK: 2.62 GHZ
PROCESS SIZE: 5NM
TRANSISTORS: 45.6 BILLION
DIE SIZE: 378 MM SQUARE
MEMORY:
MEMORY CONFIGURATION: 16GB
MEMORY INTERFACE: GDDR7
MEMORY INTERFACE WIDTH: 256 BIT
MEMORY BANDWIDTH: 960 GB/S
MEMORY CLOCK: 30 GB/S
SUPPORT:
BUS SUPPORT: PCI-E 5.0
PHYSICAL BUS INTERFACE: PCI-E 5.0 X16
SUPPORTED TECHNOLOGIES: NVIDIA BLACKWELL TECHNOLOGY, CUDA CORES TECHNOLOGY, 4TH GEN RT CORES, 5TH GEN TENSOR CORES ( AI ), HIGHER SPEED GDDR7 MEMORY, DLSS ( DLSS4, SUPER RESOLUTION, DLAA, RAY RECONSTRUCTION, FRAME GENERATION, MULTI FRAME GENERATION ), NVIDIA REFLEX ( REFLEX2, LOW LATENCY MODE, FRAME WARP ), NVIDIA BROADCAST, RESIZABLE BAR, NVIDIA APP, NVIDIA ANSEL, NVIDIA FREESTYLE, NVIDIA SHADOWPLAY, NVIDIA HIGHLIGHTS, NVIDIA G-SYNC, GAME READY DRIVERS, NVIDIA STUDIO DRIVERS, NVIDIA OMNIVERSE, RTX REMIX, MICROSOFT DIRECTX 12 ULTIMATE, NVIDIA GPU BOOST, VULKAN 1.4, OPENGL 4.6, NVIDIA ENCODER ( NVENC ) 2X 9TH GEN, NVIDIA DECODER ( NVDEC ) 2X 6TH GEN, AV1 ENCODE, AV1 DECODE, CUDA CAPABILITY 12.0, VR READY, PCI EXPRESS GEN5
NVLINK SUPPORT: NOT SUPPORTED
OPERATING SYSTEM: MICROSOFT WINDOWS 11 64 BIT / MICROSOFT WINDOWS 10 64 BIT ( NOVEMBER 2018 OR LATER ) / LINUX 64 BIT
DISPLAY SUPPORT:
MULTI MONITOR: YES, UP TO 4 DISPLAYS
DISPLAY RESOLUTION: 8K AT 165HZ WITH DSC OR 4K AT 480HZ
CONNECTIONS:
DISPLAY CONNECTORS: ( 3 ) THREE DISPLAYPORTS DP ( 1 ) ONE HDMI
POWER CONNECTORS: ( 1 ) ONE 16 PIN POWER CONNECTOR ( 12P+4P )
THERMAL AND POWER SPECS:
TOTAL POWER CONSUMPTION ( W ): 360W
MAX GPU TEMPERATURE ( IN C ): 88 DEGREES ( CELSIUS )
SYSTEM REQUIREMENTS:
RECOMMENDED PSU ( W ): 850W
MEMORY SPACE: SYSTEM MEMORY GREATER THAN OR EQUAL TO GPU MEMORY / TWICE THE GPU MEMORY OR HIGHER RECOMMENDED
COOLING SYSTEM:
ACTIVE - ( 3 ) THREE ACTIVE FANSINK ( 3 COOLING FANS )
FORM FACTOR:
TRIPLE SLOT
DIMENSIONS:
2.35 INCH ( H ) X 12.94 INCH ( L ) X 5.42 INCH ( W )
