Supermicro GPU SuperServer 741GE-TNRT Tower

The Supermicro GPU SuperServer 741GE-TNRT Tower is designed for High-Performance Computing, AI/Deep Learning Training, Cloud Gaming, 3D Rendering, and Media/Video Streaming. The system board houses dual LGA-4677 CPU sockets compatible with 4th and 5th Generation Intel Xeon Scalable processors. With 16x DDR5 DIMM slots, fully configured, the maximum memory capacity is up to 4TB. The front of the system houses 8x 3.5-inch hot-swap NVMe/SATA/SAS drive bays. The Supermicro GPU 741GE-TNRT Server can hold up to 4x double-width GPUs including, the NVIDIA H100, NVIDIA A100, NVIDIA A30, and the NVIDIA RTX A6000.

Supermicro GPU SuperServer 741GE-TNRT Tower - Specifications

Processor - 2 Sockets

5th Generation Intel Xeon Scalable Processor
4th Generation Intel Xeon Scalable Processor
Up to 64C/128T; Up to 320MB Cache per CPU
Supports up to 350W TDP CPUs (Air Cooled)

Socket:

2 x LGA-4677

Motherboard

Super X13DEG-QT

Memory

16 x DDR5 DIMM slots

Memory Capacty:

Up to 4TB: 16x 256GB DRAM

Memory Speed:

Up to 5600MHz

Drive Bays

8 x 3.5" hot-swap NVMe/SATA/SAS drive bays (8x 2.5" NVMe hybrid)

M.2:

2 x M.2 NVMe

GPU

GPU-NVH100-80,GPU-NVA100-80-NC,GPU-NVA30-NC,GPU-NVQRTX-A6000

CPU-GPU Interconnect:

PCIe 5.0 x16 CPU-to-GPU Interconnect

CPU-GPU Interconnect:

GPU-GPU Interconnect

Expansion Slots

7 x PCIe 5.0 x16 FHFL slot(s)

On-Board Devices

SATA3 (6Gbps); RAID 0/1/5/10 support

Chipset:

Intel C741 chipset

Network Controllers:

2 x 10GbE BaseT with Intel X550-AT2

IPMI:

Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Chassis

Height: 7" (178mm)

Width: 17.2" (437mm)

Depth: 29" (737mm)
