Additional InformationCPUs with up to 32x physical cores and 64 virtual threads are supported. With 8-channel memory architecture provided by the CPUs, the Supermicro 120TP-DC9TR Twin Server can provide up to 4TB of memory. Supported memory includes 3DS ECC DDR4-3200 load reduced DIMMs (LRDIMM) or Registered DIMMs (RDIMM). The drive bays are compatible with 2.5-inch SATA and SAS drives. Powering the system are dual 1000W power supply units (PSU).
There is a control panel for each of the nodes on the front of the platform. Each node also has a single PCIe 4.0 x16 low-profile slot for networking and there are also 2x 10GB RJ45 ports plus a dedicated Baseboard management controller (BMC) port. The BMC LAN port provides for remote management of the system. For management, Supermicro provides several utilities, including SuperCloud Composer (SCC), Supermicro Server Manager (SSM), Supermicro SuperDoctor 5 (SD5), and others.
Explore available configurations for the Supermicro Twin SuperServer 120TP-DC9TR. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- Dual Socket P+ (LGA-4189)
- 3rd Gen Intel Xeon Scalable processors
- Up to 32 cores/64 threads; Up to 48MB Cache per CPU
- Supports up to 185W TDP (air cooled)
- 16x DIMM slots
- Max Memory (2DPC): Up to 4TB 3200 MT/s ECC DDR4 RDIMM
- Default: Total 4x bays
- 4x front hot-swap 2.5" SAS/SATA drive bays
- Default: 1x PCIe 4.0 x16 LP slot
- 2x RJ45 10GBase-T with Intel X710-AT2
- ASPEED AST2600 BMC
- 1x RJ45 1GbE Dedicated BMC LAN port
- 2x USB 3.0 ports (rear)
- 1x VGA port
- AMI 32MB SPI Flash EEPROM
- SuperCloud Composer (SCC)
- Supermicro Server Manager (SSM)
- Supermicro Update Manager (SUM)
- Supermicro SuperDoctor 5 (SD5)
- Super Diagnostics Offline (SDO)
- Supermicro Thin-Agent Service (TAS)
- SuperServer Automation Assistant (SAA)
- ESXi 8.0, RHEL 8.3, Windows Server 2019, Windows Server 2022
- Up to 6x 4cm heavy duty fan speed control
- 2x air shrouds
- 1x 1000W Redundant Titanium Level (96%) power supply
- Height: 1.7" (43 mm)
- Width: 17.25" (438 mm)
- Depth: 28.25" (718 mm)
- Weight (Gross): 48.1 lbs (21.9 kg)
- Weight (Net): 33.5 lbs (15.2 kg)
