Additional InformationProviding the processing foundation are 2x AMD EPYC 9755 processors, each offering 128 cores and 256 threads with a maximum cTDP of up to 500W. Memory capacity reaches up to 6TB across 24x DDR5 DIMM slots, with support for RDIMMs and 3DS RDIMMs at speeds of up to 6400MT/s. Located on the front panel are 8x hot-swappable U.2 NVMe bays for local storage, complemented by 2x internal NVMe M.2 2280 slots. High-bandwidth connectivity is available through 12x PCIe Gen5 x16 slots, consisting of 4x full-height, half-length slots and 8x half-height, half-length slots for networking and expansion.
Accelerated workloads are handled by 8x AMD Instinct MI355X GPUs, each featuring 288GB of HBM3E memory. Delivering power to the GPU subsystem is a 3+3 redundant 15,600W 54V DC configuration, accompanied by 1+1 redundant 3,200W 12V DC Titanium CRPS. Direct liquid cooling is used for both the CPUs and GPUs.
- 2x AMD EPYC 9755
- 2x AMD Socket SP5
- Max up to 500W (cTDP)
- 24x DIMM slots
- Up to 6TB RDIMM DDR5-6400 memory
- 12x Channels per CPU
- 8x AMD Instinct MI355X
- 8x NVMe U.2 hot-swap bays
- 2x NVMe M.2 2280 slots
- 4x PCIe Gen 5 x16 slots (FH/HL) (8) PCIe Gen 5 x16 slots (HH/HL)
PHY: Realtek RTL8211FD-CG
- 3+3 (15,600W; 54VDC) 1+1 (3,200W; 12VDC)
- 80 plus Titanium
Air: 4x 6056 hot-swap fans (UBB) 4x 8038 hot-swap fans (Head Node) 4x 4056 internal fans (PCIe)
Liquid: 4x UQD06 conn. (UBB) (2) UQD02 conn. (Head Node)
- Aspeed AST2600
Form Factor: 4U Rackmount
Dimension (D x W x H): 36.52" x 17.64" x 6.85" (927.6 x 448 x 174mm)
Gross Weight: 130 kg (286.6 lbs)
Net Weight: 100 kg (220.5 lbs)
