Additional InformationThe MiTAC GS73B8056 B8056G73E16HR-2T-TU-HE features 1x AMD EPYC 9005 or 9004 Series processor with a maximum TDP of 320W using an EVAC heatsink. The system provides 24x DDR5 RDIMM slots supporting up to 6TB of system memory at speeds of up to 6400MT/s. For storage, the chassis provides a high-density, all-flash configuration with 16x hot-swappable E3.S NVMe SSD bays on the front panel, each with PCIe Gen5 x4 connectivity. An additional 2x internal NVMe M.2 2280/22110 slots provide storage for boot drives or other system requirements.
Expansion is provided by 2x PCIe Gen5 x16 slots along with 1x OCP 3.0 mezzanine slot. Integrated networking includes 2x 10GbE ports along with a dedicated IPMI management port. An integrated ASPEED AST2600 BMC provides remote system monitoring and management with support for IPMI, iKVM, and Redfish. The platform is cooled by 6x 4056 system fans and features 1+1 redundant 2000W hot-swappable power supplies with 80 PLUS Titanium efficiency.
- 1x AMD EPYC 9005 / 9004 Series Processor
- 1x AMD Socket SP5
- Max up to 320W* (cTDP) w/ EVAC Heatsink
- Ambient temperature 27℃ when cTDP @ 320W
- 24x DIMM slots
- Up to 6TB RDIMM DDR5 memory
- 12x Channels per CPU
- RDIMM DDR5-5200 MT/s (EPYC 9005 w/ 1DPC) / RDIMM DDR5-4000 MT/s (EPYC 9005 w/ 2DPC) / RDIMM DDR5-4800 MT/s (EPYC 9004 w/ 1DPC) / RDIMM DDR5-3600 MT/s (EPYC 9004 w/ 2DPC)
- 16x NVMe E3.s-1T hot-swap bays (PCIe Gen 5)
- 2x NVMe M.2 2280/22110 slots
- 2x PCIe Gen 5 x16 slots (FH/HL)
- 1x OCP v3.0 mezz. slot (SFF)
- 2x USB 3.2 Gen 1 ports
- 1x D-sub 15-pin port
- 2x 10GbE ports
- 1x DB-9 COM port
- 1x GbE port dedicated for IPMI
Controller:
- 1x Intel X710-AT2
PHY:
- Realtek RTL8211FD-CG
- 1x USB 3.2 Gen 1 port
- 1+1 2,000W hot-swap RPSU, 80+ Titanium
- 6x 4056 System fans
- Aspeed AST2600
Dimension (D x W x H): 28.74" x 17.26" x 1.69" (730 x 438.5 x 43mm)
Gross Weight: 26.73kg
Net Weight: 16.76kg
