Additional InformationThis system supports 8x DDR5 RDIMM memory modules. Up to 8x 3.5 storage bays support SATA drive types. That includes 4x standard 3.5-inch drives bays and 4x more optional 3.5-inch drive bays can be installed. Additional super-fast storage in the form of up to 4x M.2 PCIe Gen5 x4 drives can be installed. Another slot provides support for a M.2 form factor Wi-Fi card. The Gigabyte W773-H5D GPU Workstation is designed for AI, Visual Computing, High-Performance Computing, use as a Hybrid/Private Cloud Server, AI Training, and AI Inference.
Configuration Options:
Gigabyte W773-H5D-AAF1 GPU Workstation
Single 2500W ATX 80 Plus Platinum PSU, AC Input - 200-240V~, 15A, 50-60Hz
Gigabyte W773-H5D-AA01 GPU Workstation
Single 2000W ATX 80 Plus Gold PSU, AC Input - 100-240V~/ 15-12A, 60-50Hz
The system features 2x 10Gb/s LAN ports via a Broadcom BCM57416. 6x PCIe Gen5 x16 slots provide support for Networking, drive controllers, and GPU options.
GPU Configurations:
NVIDIA RTX PRO™ 6000 Blackwell Workstation Edition: 1 x GPU
NVIDIA RTX PRO™ 6000 Blackwell Max-Q Workstation Edition: 4 x GPUs
NVIDIA RTX™ 6000 Ada Generation: 4 x GPUs
AMD Radeon™ AI PRO R9700: 4 x GPUs
Triple-slot GPUs: 2 x GPUs
This system can also be rack mounted using an optional rail kit.
Explore available configurations for the Gigabyte W773-H5D GPU Workstation. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
- AMD Ryzen Threadripper PRO 9000 WX-Series Processors
- AMD Ryzen Threadripper PRO 7000 WX-Series Processors
- Single Processor, TDP up to 350W
- Socket: 1 x sTR5
- Chipset: AMD WRX90
- Motherboard: MH53-G40
- 8x DIMM slots
- Support DDR5 RDIMM
- 8-Channel memory per processor
Ryzen Threadripper PRO 9000 WX:
- Up to 6400 MT/s
Ryzen Threadripper PRO 7000 WX:
- Up to 5200 MT/s
- 2x 10 Gb/s LAN (1 x Broadcom BCM57416)
- Support NCSI function
- 1x 10/100/1000 Mb/s Management LAN
Front hot-swap:
- 4x 3.5"/2.5" SATA
Optional: 4 x 3.5"/2.5" SATA
Internal M.2:
- 4x M.2 (2280/22110), PCIe Gen5 x4, from CPU
Note: Storage card is required to support NVMe and SAS drives.
- RAID 0/1/10/5
- 5.25" space reserved for ODD device
- Slot_7: PCIe x16 (Gen5 x16)
- Slot_6: PCIe x16 (Gen5 x16)
- Slot_5: PCIe x16 (Gen5 x16)
- Slot_3: PCIe x16 (Gen5 x16)
- Slot_2: PCIe x16 (Gen5 x16)
- Slot_1: PCIe x16 (Gen5 x16)
- 1x M.2 (2230), E-key (Wi-Fi), PCIe Gen3 x1, from FCH
- 1x USB 3.2 Gen1 port (Type-C)
- 2x USB 3.2 Gen1 ports (Type-A)
- 2x Audio jacks (Audio out/Mic)
- 1x Power button with LED
- 1x Reset button
- 1x Power LED
- 1x Storage activity LED
- 1x System status LED
- 1x USB 3.2 Gen2x2 port (Type-C) (from FCH)
- 3x USB 3.2 Gen2x1 ports (Type-A) (from CPU)
- 1x VGA port
- 1x Serial port
- 2x RJ45 ports
- 1x MLAN port
- 3x Audio jacks (Audio in/Audio out/Mic)
- 1x ID button with LED
AA01:
- Single 2000W ATX 80 PLUS Gold power supply
AAF1:
- Single 2500W ATX 80 PLUS Platinum power supply
- Pedestal
- 218 x 455 x 726.3
- Net Weight: 29.2 kg
- Gross Weight: 34.4 kg
