Additional InformationThe W793-ZU0 supports 12-channel memory across 12x DDR5 DIMM slots, with memory speeds reaching up to 6400 MT/s when paired with AMD EPYC 9005 processors. It also includes 4x front-access 2.5-inch Gen5 NVMe drive bays and 3x 2400W 80 PLUS Titanium redundant power supplies lining the top of the rear panel.
Built for high-speed expansion and connectivity, the W793-ZU0 includes 7x PCIe Gen5 x16 expansion slots, with 4x FHFL slots dedicated to GPUs and 3x FHHL slots for high-performance networking cards. The system also features dual 10 Gb/s LAN ports via the Intel X550-AT2 controller and integrated ASPEED AST2600 graphics with 1x Mini-DP output. Advanced remote management is available through the Gigabyte Management Console, making the system ideal for AI training, inference, simulation, rendering, and large-scale data processing workloads.
Explore available configurations for the Gigabyte W793-ZU0 GPU Workstation. Each configuration includes a specific combination of components and options to meet different performance, cooling, storage, and deployment requirements.
Front hot-swap:
• 4x 2.5" Gen5 NVMe
Front (I/O board - CFPX142):
• 2 x 10 Gb/s LAN (1 x Intel X550-AT2)
• Support NCSI function
1x 10/100/1000 Mb/s Management LAN
Integrated in ASPEED AST2600
• 1x Mini-DP
PCIe Cable x 7:
• 4 x FHFL x16 (Gen5 x16), for GPUs
• 3 x FHHL x16 (Gen5 x16), for NICs
Note: The system is only validated with a uniform GPU model.
I/O board - CFPX142:
• 2 x USB 3.2 Gen1 ports (Type-A)
• 1 x Mini-DP
• 2 x RJ45 ports
• 1 x MLAN port
• 1 x Power button with LED
• 1 x Power button with LED
• 1 x Reset button
• 1 x Storage activity LED
• 1 x System status LED
N/A
Pedestal
• 218 x 449 x 780
