CPUs with 18 to 86 physical cores and up to 172 virtual threads can be installed in the HP Z8 Fury G6i Workstation. Each processor delivers 8x memory channels, and with 16x DDR5 memory module slots it can be outfitted with 2x DIMMs per Channel (2DPC) for up to 2TB. Memory speeds of up to 6400MT/s are supported. The front of the system offers two different options for I/O ports. The entry-level panel includes 4x USB type-A ports offering 5Gb/s data transfer rates, and a Premium panel that offers 2x USB type-A ports and 2x USB type-C ports providing 20Gb/s transfer rates. The back of the system provides more ports.
Supported Operating Systems
- Windows 11 Pro for Workstations
- Ubuntu 24.04 LTS
- Linux Ready
- Red Hat Enterprise Linux
A 5.25-inch media bay on the front of the chassis can be outfitted with an optical device or 2-4 NVMe M.2 drives each with a lockable drive bay for security. Inside the chassis are 2x 3.5-inch SATA drive bays plus 4x PCIe 5.0 x4 slots on the system board for NVMe M.2 drives. The system also offers 9x PCIe slots for expansion and additional storage with an HP Z Turbo Drive Quad Pro PCIe SSD card. The PCIe slots can also support optional networking, GPUs, and Thunderbolt 5 technology for superfast data transfers.
Up to 4x 300W GPUs, including the NVIDIA RTX Pro 6000 Blackwell Max-Q GPUs. Additionally, the Z8 Gen6 will also support a single 600W GPU or a single quad-wide GPU. A Max Side Panel can be installed instead of the standard side panel and provides enhanced cooling and more space for larger GPUs and those with a higher Thermal Design Power (TDP) threshold.
Power is provided by either a single or dual redundant power supply that can deliver up to 1350W when connected to a 120V standard outlet or up to 1700W when connected to a 208-240V single-phase socket. With 2x PSUs installed, they can be configured in aggregate mode to deliver up to 2700W with a standard outlet or up to 3400W with a single-phase socket. With aggregate mode enabled there is no redundancy.
- Intel Xeon 698X (2.0 GHz base frequency, up to 4.8 GHz with Intel Turbo Boost Technology, 336 MB L3 cache, 86 cores, 174 threads, 350W)
- Intel Xeon 696X (2.4 GHz base frequency, up to 4.8 GHz with Intel Turbo Boost Technology, 336 MB L3 cache, 64 cores, 128 threads, 350W)
- Intel Xeon 678X (2.4 GHz base frequency, up to 4.9 GHz with Intel Turbo Boost Technology, 192 MB L3 cache, 48 cores, 96 threads, 300W)
- Intel Xeon 676X (2.8 GHz base frequency, up to 4.9 GHz with Intel Turbo Boost Technology, 144 MB L3 cache, 32 cores, 64 threads, 275W)
- Intel Xeon 674X (3.0 GHz base frequency, up to 4.9 GHz with Intel Turbo Boost Technology, 144 MB L3 cache, 28 cores, 56 threads, 270W)
- Intel Xeon 658X (3.0 GHz base frequency, up to 4.9 GHz with Intel Turbo Boost Technology, 144 MB L3 cache, 24 cores, 48 threads, 250W)
- Intel Xeon 656 (2.9 GHz base frequency, up to 4.8 GHz with Intel Turbo Boost Technology, 72 MB L3 cache, 20 cores, 40 threads, 210W)
- Intel Xeon 654 (3.1 GHz base frequency, up to 4.8 GHz with Intel Turbo Boost Technology, 72 MB L3 cache, 18 cores, 36 threads, 200W)
- Intel W890
- 16x DIMM, 8x memory channels supporting 2x DIMMs per channel
- 2TB DDR5 6400MT/s ECC
- Transfer rates up to 6400MT/s
Memory Card Device: 1x SD card reader (optional)
- 2x NVMe M.2 SSD
- 1x 3.5" HDD
- 2x 9.5 mm ODD
- 8x PCIe M.2 SSD
- 2x 3.5" HDD
Internal Storage
- 4 TB up to 12 TB 7200 rpm SATA Enterprise HDD
- 512 GB up to 8 TB HP Z Turbo Drive NVMe M.2 SSD
- 512 GB up to 8 TB HP Z Turbo Drive PCIe M.2 Front Load Removable SSD
- 512 GB up to 4 TB HP Z Turbo Drive PCIe SED Opal 2 M.2 SSD
- 1 TB up to 4 TB HP Z Turbo Drive Quad Pro PCIe SSD
Optical Drive
- HP Slim DVD-ROM; HP Slim DVD-Writer
Ultra High-End
- NVIDIA A800 (40 GB GDDR6 dedicated); NVIDIA RTX Pro 6000 Blackwell Generation (96 GB GDDR7 dedicated)
High-End
- NVIDIA RTX Pro 5000 Blackwell Generation (48 GB GDDR7 dedicated); NVIDIA RTX Pro 4500 Blackwell Generation (32 GB GDDR7 dedicated)
Mid-Range
- NVIDIA RTX Pro 4000 Blackwell Generation (24 GB GDDR7 dedicated); NVIDIA RTX Pro 2000 Blackwell Generation (16 GB GDDR7 dedicated)
Entry
- NVIDIA RTX A1000 (8 GB GDDR6 dedicated) (NVIDIA Max-Q technology)
9x PCIe Slots
- 4x PCIe 5 x16
- 3x PCIe 5 x8
- 1x PCIe 5 x4
- 1x PCIe 4 x4
Note: All PCIe slots are accessible through the rear bulkhead
Front
- Entry: 4 USB Type-A 5Gbs signaling rate (1 charging), 1 headphone/microphone combo
Rear
- 1 USB Type-C 20Gbps signaling rate; 5 USB Type-A 5Gbps signaling rate
Optional Ports
- Flex IO Rear - Dual Type-A 3.2 Gen1 Flex IO v2; Dual Type-C 3.2 G2 15W Out Flex IO; HP Serial Port v3 Flex IO; HP 1 GbE LC Fiber Flex IO port; HP 10 GBASE-T Flex IO port; HP Flex IO 1 GbE single-port NIC; HP 2.5 GbE Flex IO port; 2 Thunderbolt 5 with USB Type-C 40Gbps signaling rate (USB Power Delivery, DisplayPort 1.4)
Front Premium
- 2 USB Type-A 5Gbps signaling rate (1 charging), 2 USB Type-C 20Gbps signaling rate, 1 headphone/microphone combo
- 1700W internal power supply, up to 92% efficiency, active PFC
- 1350W internal power supply, up to 92% efficiency, active PFC
- 2700W aggregate internal power supply, up to 92% efficiency, active PFC
- 1700W redundant internal power supply, up to 92% efficiency, active PFC
- 1350W redundant internal power supply, up to 92% efficiency, active PFC
- All HP Z Displays and HP DreamColor Displays are supported.
- Windows 11 Pro for Workstations
- Ubuntu 24.04 LTS Linux
- Ready Red Hat
- Enterprise Linux
- 17.5 x 8.6 x 22 in (without rear handle)
- 17.5 x 10 x 22 in (max side panel without rear handle)
- 44.51 x 21.95 x 55.9 cm (without rear handle)
- 44.5 x 25.35 x 55.9 cm (max side panel without rear handle)
- Rack dimensions: 5U with standard side panel, 6U with max side panel. Standard desktop orientation
- Starting at 48.9 lb (22.2 kg)
Note: Exact weight depends on configuration.
