LENOVO MOTHERBOARD (SB20A35749)

Product Details:

LENOVO MOTHERBOARD FOR LENOVO THINKSTATION P720 TOWER WORKSTATION - LEWISBURG SYSTEM BOARD VOLGA V1.0

MANUFACTURER: LENOVO
PART NUMBER: SB20A35749
COMPATIBILITY: LENOVO THINKSTATION P720 TOWER WORKSTATION

PROCESSOR DETAIL

NUMBER OF PROCESSORS SUPPORTED: ( 2 ) TWO PROCESSORS
SOCKET TYPE: FCLGA3647
PROCESSOR CORE COUNT: UP TO 24 CORES AT 2.1GHZ OR 4 CORES AT 3.6GHZ

MEMORY DETAIL

NUMBER OF MEMORY SLOTS: 12 TOTAL MEMORY SLOTS ( 12 CHANNELS, 6 CHANNELS PER PROCESSOR )
MEMORY TYPE: UP TO DDR4-2933 ( SPEEDS DEPEND ON PROCESSOR SPECIFICATION )
RDIMM MEMORY SIZE CAPACITY: UP TO 768GB ( DDR4-2933 ) OR UP TO 384GB ( DDR4-2666 )

PCI INTERFACE DETAIL

NUMBER OF PCI SLOTS: 6 INTERFACES ( ONBOARD )

- SLOT1 PCI-E 3.0 X16 ( CPU2 ) ( 75W / FULL HEIGHT, FULL LENGTH )
- SLOT2 PCI-E 3.0 X16 ( CPU1 ) ( 75W / DOUBLE WIDTH / FULL HEIGHT, FULL LENGTH )
- SLOT3 PCI-E 3.0 X8 ( CPU1 ) ( 25W / OPEN END / FULL HEIGHT, FULL LENGTH )
- SLOT4 PCI-E 3.0 X16 ( CPU1 ) ( 75W / DOUBLE WIDTH / FULL HEIGHT, FULL LENGTH )
- SLOT5 PCI-E 3.0 X4 ( 75W / FULL HEIGHT, FULL LENGTH )
- SLOT6 PCI-E 3.0 X8 ( PCH ) ( 25W / OPEN END / FULL HEIGHT, HALF LENGTH )
