SAPPHIRE NITRO+ AMD RADEON RX 6700 XT GAMING OC GPU 12GB 2560 STREAM CORES MEMORY INTERFACE 192 BIT GDDR6 PCI-E 4.0 X16 ( 3 ) THREE DISPLAYPORTS DP ( 1 ) ONE HDMI GRAPHICS PROCESSING UNIT VIDEO CARD (S88-1E445-000FT-RETAIL)

Product Details:

SAPPHIRE NITRO+ AMD RADEON RX 6700 XT GAMING OC GPU 12GB 2560 STREAM CORES MEMORY INTERFACE 192 BIT GDDR6 PCI-E 4.0 X16 ( 3 ) THREE DISPLAYPORTS DP ( 1 ) ONE HDMI GRAPHICS PROCESSING UNIT VIDEO CARD

MANUFACTURER: SAPPHIRE / AMD
PART NUMBER: S88-1E445-000FT-RETAIL

ENGINE SPECS:

ENGINE ARCHITECTURE: AMD RDNA 2 ( RDNA2 )
GPU PROCESSOR: NAVI 21
STREAM PROCESSORS: 2560
GPU CLOCK: 2457 MHZ
GAME CLOCK: 2548 MHZ
BOOST CLOCK: 2622 MHZ

MEMORY:

MEMORY CONFIGURATION: 12GB
MEMORY INTERFACE: GDDR6
MEMORY INTERFACE WIDTH: 192 BIT
MEMORY BANDWIDTH: 384 GB/S
MEMORY CLOCK: 16 GB/S

SUPPORT:

BUS SUPPORT: PCI-E 4.0
PHYSICAL BUS INTERFACE: PCI-E 4.0 X16
AMD SUPPORTED TECHNOLOGIES: AMD RDNA 2 GAMING ARCHITECUTRE, DIRECTX 12 ULTIMATE, HARDWARE RAYTRACING, SMART ACCESS MEMORY, INFINITY CACHE, RADEON ANTI-LAG, 7NM TECHNOLOGY, AMD FREESYNC TECHNOLOGY, RADEON VR READY PREMIUM, AMD FIDELITYFX, RADEON IMAGE SHARPENING, RADEON ANTI-LAG, RADEON SOFTWARE, GAME DRIVER OPTIMIZATIONS, OPENGL SUPPORT, OPENCL SUPPORT, GDDR6, PCI EXPRESS GEN4
SAPPHIRE SUPPORTED TECHNOLOGIES: DUAL BIOS, TRIXX SOFTWARE BIOS SWITCH, PREMIUM DIGITAL POWER DESIGN, FUSE PROTECTION, TRI-X COOLING TECHNOLOGY, INTELLIGENT FAN CONTROL, PRECISION FAN CONTROL, BACKPLATE WITH ARGB, TWO-BALL BEARING FANS, HYBRID FAN BLADE, WAVE FIN DESIGN, V SHAPE FIN DESIGN FOR GPU COOLING, INTEGRATED COOLING MODULE, TRIXX SUPPORTED, FAN CHECK, FAN QUICK CONNECT, TRIXX BOOST, NITRO GLOW, EXTERNAL RGB LED MB SYNCHRONIZATION

DISPLAY SUPPORT:

MULTI MONITOR: YES ( UP TO 4 MONITORS )
RESOLUTION: 7680 X 4320

CONNECTIONS:

DISPLAY CONNECTORS: ( 3 ) THREE DISPLAYPORTS ( DP 1.4 WITH DSC ) ( 1 ) ONE HDMI ( 2.1 VRR )
POWER CONNECTORS: ( 1 ) ONE 8 PIN POWER CONNECTOR ( 1 ) ONE 6 PIN POWER CONNECTOR

SYSTEM REQUIREMENTS:

MEMORY: 8GB MINIMUM / 16GB RECOMMENDED
RECOMMENDED POWER SUPPLY ( W ): 650W

THERMAL AND POWER SPECS:

BOARD MAX POWER CONSUMPTION ( W ): 260W

OPERATING SYSTEM:

MICROSOFT WINDOWS 7 ( DOES NOT SUPPORT ALL FEATURES INCLUDING BUT NOT LIMITED TO HARDWARE RAYTRACING )
MICROSOFT WINDOWS 8.1 64 BIT
MICROSOFT WINDOWS 10
LINUX

COOLING SYSTEM:

ACTIVE TRI-X COOLING TECH - ( 3 ) THREE ACTIVE FANS ( TRIPLE ACTIVE FANSINK )

FORM FACTOR:

2.5 SLOT, FULL HEIGHT

DIMENSION:

12.2 X 5.1 X 2 INCH
