NVIDIA A30 TENSOR CORE GPU ACCELERATOR 24GB HBM2 MEMORY INTERFACE 3072 BIT MEMORY BANDWIDTH 933GB/S PCI-E 4.0 X16 COMPUTE GENERAL PURPOSE GRAPHICS PROCESSING UNIT GPGPU - AMPERE TECHNOLOGY PASSIVE HEATSINK (NVIDIA A30)

Product Details:

NVIDIA A30 TENSOR CORE GPU ACCELERATOR 24GB HBM2 MEMORY INTERFACE 3072 BIT MEMORY BANDWIDTH 933GB/S PCI-E 4.0 X16 COMPUTE GENERAL PURPOSE GRAPHICS PROCESSING UNIT GPGPU - AMPERE TECHNOLOGY PASSIVE HEATSINK

MANUFACTURER: NVIDIA
PART NUMBER: NVIDIA A30

ENGINE SPECS:

ENGINE ARCHITECTURE: AMPERE
GPU CLOCK ( BASE ): 930 MHZ
BOOST CLOCK: 1440 MHZ
PEAK FP64: 5.2TF ( TERAFLOPS )
PEAK FP64 TENSOR CORE: 10.3TF ( TERAFLOPS )
PEAK FP32: 10.3TF ( TERAFLOPS )
FP32 TENSOR CORE: 82TF ( TERAFLOPS ) / 165TF ( TERAFLOPS WITH SPARSITY )
BFLOAT16 TENSOR CORE: 165TF / 330TF ( TERAFLOPS WITH SPARSITY )
PEAK FP16 TENSOR CORE: 165TF / 330TF ( TERAFLOPS WITH SPARSITY )
PEAK INT8 TENSOR CORE: 330 TOPS / 661 TOPS ( WITH SPARSITY )
PEAK INT4 TENSOR CORE: 661 TOPS / 1321 TOPS ( TERAFLOPS )
NVLINK TRANSFER SPEEDS: 200GB/S ( TOTAL MAX BANDWIDTH )

MEMORY:

MEMORY CONFIGURATION: 24GB
MEMORY INTERFACE: HBM2
MEMORY INTERFACE WIDTH: 3072 BIT
MEMORY BANDWIDTH: 933GB/S
MEMORY CLOCK: 1215 MHZ
ERROR CORRECTION CODE ( ECC ): YES ( ENABLED BY DEFAULT / CAN BE DISABLED VIA SOFTWARE )

SUPPORT:

BUS SUPPORT: PCI-E 4.0
PHYSICAL BUS INTERFACE: PCI-E 4.0 X16 ( 64GB/S )
SUPPORTED TECHNOLOGIES: 3RD GEN NVIDIA NVLINK, NVIDIA AI ENTERPRISE, NVIDIA VIRTUAL COMPUTE SERVER, PCIE GEN4
OPERATING SYSTEMS: MICROSOFT WINDOWS 7, MICROSOFT WINDOWS 8.1, MICROSOFT WINDOWS 10, MICROSOFT WINDOWS SERVER 2008 R2, MICROSOFT WINDOWS SERVER 2012 R2, LINUX ( ENGLISH US / UK )

CONNECTIONS:

POWER CONNECTORS: ( 1 ) ONE 8 PIN AUXILIARY POWER CONNECTOR
ADDITIONAL: ( 1 ) ONE NVLINK INTERFACE ( 3RD GEN )

THERMAL AND POWER SPECS:

MAX POWER CONSUMPTION ( W ): 165W

COOLING SYSTEM:

PASSIVE HEATSINK ( BIDIRECTIONAL AIRFLOW )

FORM FACTOR:

DUAL SLOT, FULL HEIGHT / HIGH PROFILE

DIMENSIONS:

10.5 INCH ( L ) X 4.5 INCH ( H )
